Modify from the article "A simple exercise of Video Capture using MediaRecorder, for Android 2.3 or higher":
package com.exercise.AndroidVideoCapture;
import java.io.IOException;
import android.app.Activity;
import android.content.Context;
import android.hardware.Camera;
import android.hardware.Camera.Parameters;
import android.media.CamcorderProfile;
import android.media.MediaRecorder;
import android.os.Bundle;
import android.view.MotionEvent;
import android.view.SurfaceHolder;
import android.view.SurfaceView;
import android.view.View;
import android.widget.Button;
import android.widget.FrameLayout;
import android.widget.RadioButton;
import android.widget.Toast;
public class AndroidVideoCapture extends Activity{
private Camera myCamera;
private MyCameraSurfaceView myCameraSurfaceView;
private MediaRecorder mediaRecorder;
Button myButton;
RadioButton flashOff, flashTorch;
SurfaceHolder surfaceHolder;
boolean recording;
/** Called when the activity is first created. */
@Override
public void onCreate(Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
recording = false;
setContentView(R.layout.main);
//Get Camera for preview
myCamera = getCameraInstance();
if(myCamera == null){
Toast.makeText(AndroidVideoCapture.this,
"Fail to get Camera",
Toast.LENGTH_LONG).show();
}
myCameraSurfaceView = new MyCameraSurfaceView(this, myCamera);
FrameLayout myCameraPreview = (FrameLayout)findViewById(R.id.videoview);
myCameraPreview.addView(myCameraSurfaceView);
myButton = (Button)findViewById(R.id.mybutton);
myButton.setOnClickListener(myButtonOnClickListener);
flashOff = (RadioButton)findViewById(R.id.flashoff);
flashTorch = (RadioButton)findViewById(R.id.flashtorch);
}
Button.OnTouchListener flashButtonOnTouchListener
= new Button.OnTouchListener(){
@Override
public boolean onTouch(View arg0, MotionEvent arg1) {
// TODO Auto-generated method stub
if(myCamera != null){
Parameters parameters = myCamera.getParameters();
switch (arg1.getAction()){
case MotionEvent.ACTION_DOWN:
parameters.setFlashMode(Parameters.FLASH_MODE_TORCH);
myCamera.setParameters(parameters);
break;
case MotionEvent.ACTION_UP:
parameters.setFlashMode(Parameters.FLASH_MODE_OFF);
myCamera.setParameters(parameters);
break;
};
}
return true;
}};
Button.OnClickListener flashModeButtonOnClickListener
= new Button.OnClickListener(){
@Override
public void onClick(View v) {
// TODO Auto-generated method stub
}
};
Button.OnClickListener myButtonOnClickListener
= new Button.OnClickListener(){
@Override
public void onClick(View v) {
// TODO Auto-generated method stub
if(recording){
// stop recording and release camera
mediaRecorder.stop(); // stop the recording
releaseMediaRecorder(); // release the MediaRecorder object
//Exit after saved
finish();
}else{
//Release Camera before MediaRecorder start
releaseCamera();
if(!prepareMediaRecorder()){
Toast.makeText(AndroidVideoCapture.this,
"Fail in prepareMediaRecorder()!\n - Ended -",
Toast.LENGTH_LONG).show();
finish();
}
mediaRecorder.start();
recording = true;
myButton.setText("STOP");
}
}};
private Camera getCameraInstance(){
// TODO Auto-generated method stub
Camera c = null;
try {
c = Camera.open(); // attempt to get a Camera instance
}
catch (Exception e){
// Camera is not available (in use or does not exist)
}
return c; // returns null if camera is unavailable
}
private String getFlashModeSetting(){
if(flashTorch.isChecked()){
return Parameters.FLASH_MODE_TORCH;
}else {
return Parameters.FLASH_MODE_OFF;
}
}
private boolean prepareMediaRecorder(){
myCamera = getCameraInstance();
Parameters parameters = myCamera.getParameters();
parameters.setFlashMode(getFlashModeSetting());
myCamera.setParameters(parameters);
mediaRecorder = new MediaRecorder();
myCamera.unlock();
mediaRecorder.setCamera(myCamera);
mediaRecorder.setAudioSource(MediaRecorder.AudioSource.CAMCORDER);
mediaRecorder.setVideoSource(MediaRecorder.VideoSource.CAMERA);
mediaRecorder.setProfile(CamcorderProfile.get(CamcorderProfile.QUALITY_HIGH));
mediaRecorder.setOutputFile("/sdcard/myvideo.mp4");
mediaRecorder.setMaxDuration(60000); // Set max duration 60 sec.
mediaRecorder.setMaxFileSize(5000000); // Set max file size 5M
mediaRecorder.setPreviewDisplay(myCameraSurfaceView.getHolder().getSurface());
try {
mediaRecorder.prepare();
} catch (IllegalStateException e) {
releaseMediaRecorder();
return false;
} catch (IOException e) {
releaseMediaRecorder();
return false;
}
return true;
}
@Override
protected void onPause() {
super.onPause();
releaseMediaRecorder(); // if you are using MediaRecorder, release it first
releaseCamera(); // release the camera immediately on pause event
}
private void releaseMediaRecorder(){
if (mediaRecorder != null) {
mediaRecorder.reset(); // clear recorder configuration
mediaRecorder.release(); // release the recorder object
mediaRecorder = null;
myCamera.lock(); // lock camera for later use
}
}
private void releaseCamera(){
if (myCamera != null){
myCamera.release(); // release the camera for other applications
myCamera = null;
}
}
public class MyCameraSurfaceView extends SurfaceView implements SurfaceHolder.Callback{
private SurfaceHolder mHolder;
private Camera mCamera;
public MyCameraSurfaceView(Context context, Camera camera) {
super(context);
mCamera = camera;
// Install a SurfaceHolder.Callback so we get notified when the
// underlying surface is created and destroyed.
mHolder = getHolder();
mHolder.addCallback(this);
// deprecated setting, but required on Android versions prior to 3.0
mHolder.setType(SurfaceHolder.SURFACE_TYPE_PUSH_BUFFERS);
}
@Override
public void surfaceChanged(SurfaceHolder holder, int format, int weight,
int height) {
// If your preview can change or rotate, take care of those events here.
// Make sure to stop the preview before resizing or reformatting it.
if (mHolder.getSurface() == null){
// preview surface does not exist
return;
}
// stop preview before making changes
try {
mCamera.stopPreview();
} catch (Exception e){
// ignore: tried to stop a non-existent preview
}
// make any resize, rotate or reformatting changes here
// start preview with new settings
try {
mCamera.setPreviewDisplay(mHolder);
mCamera.startPreview();
} catch (Exception e){
}
}
@Override
public void surfaceCreated(SurfaceHolder holder) {
// TODO Auto-generated method stub
// The Surface has been created, now tell the camera where to draw the preview.
try {
mCamera.setPreviewDisplay(holder);
mCamera.startPreview();
} catch (IOException e) {
}
}
@Override
public void surfaceDestroyed(SurfaceHolder holder) {
// TODO Auto-generated method stub
}
}
}
main.xml
<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
android:orientation="vertical"
android:layout_width="fill_parent"
android:layout_height="fill_parent"
>
<LinearLayout
android:orientation="horizontal"
android:layout_width="fill_parent"
android:layout_height="fill_parent"
>
<FrameLayout
android:id="@+id/videoview"
android:layout_width="720px"
android:layout_height="480px"/>
<LinearLayout
android:orientation="vertical"
android:layout_width="fill_parent"
android:layout_height="fill_parent">
<Button
android:id="@+id/mybutton"
android:layout_width="fill_parent"
android:layout_height="wrap_content"
android:text="REC"
android:textSize="12dp"/>
<RadioGroup
android:layout_width="fill_parent"
android:layout_height="wrap_content"
android:orientation="vertical">
<RadioButton
android:id="@+id/flashoff"
android:layout_width="wrap_content"
android:layout_height="wrap_content"
android:text="OFF"
android:textSize="8dp"
android:checked="true"/>
<RadioButton
android:id="@+id/flashtorch"
android:layout_width="wrap_content"
android:layout_height="wrap_content"
android:text="Torch"
android:textSize="8dp"/>
</RadioGroup>
</LinearLayout>
</LinearLayout>
</LinearLayout>
Refer to the article "A simple exercise of Video Capture using MediaRecorder, for Android 2.3 or higher" for AndroidManifest.xml.
Download the files.
